Hot Spring®

PRISM™ | Limelight® | $$$$ | 7 Seats

PRISM™ | Limelight® | $$$$ | 7 Seats

The extra large Prism is a premium seven-seat spa with a relaxing lounge seat and the JetStream® XL jet for an exceptional foot and leg massage.

PEOPLE  7
SEATING Lounge
VOLTAGE 230 V
DIMENSIONS 9'2" x 7'7" x 38"
WATER CARE FreshWater® Salt System Included
View full details

VIEW THIS SPA IN YOUR SPACE

Shop and compare models virtually, in any color combination, and see how they look in your space with the Virtual View™AR app.

KEY SPECS

TOTAL SEATS

7 Seats (1 Lounge Included)

DIMENSIONS

9’2” x 7’7” x 38”
279 cm x 231 cm x 97 cm

JETS & JET PUMPS

73 Jets

1 - JetStream®XL
1 - XL Dual Rotary
2 - XL Single Rotary
3 - XL Directional
7 - Standard Dual Rotary
4 - Standard Single Rotary
4 - Standard Directional
10 - Rotary Precision®
41 - Directional Precision®

Jet Pump 1
Wavemaster®9200
Two-Speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque

Jet Pump 2
Wavemaster®9000
One-Speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque

Jet Pump 3
Wavemaster®9000
One-Speed
2.5 HP Continuous Duty
5.2 HP Breakdown Torque

WATER CARE SYSTEM

FreshWater®Salt System Included

SMART MONITORING SYSTEM

FreshWater®IQ System Ready

VOLTAGE

230V

WATER CAPACITY & WEIGHT

Water Capacity: 525 g / 1,990 L
Dry Weight: 1,190 lb. / 540 kg
Filled Weight: 6,795 lb. / 3,085 kg

ADVANCED DESIGNS AND FEATURES. A CUT ABOVE.

THE LEGENDARY HOT SPRING® MASSAGE

Comfortable seats with purposefully arranged jet systems that work together to target specific muscle groups. The result is a distinctive massage for your neck, shoulders, back, wrists, calves, and feet.

EASY WATER CARE

Crystal clear water is essential to a great spa experience. The Limelight Collection® offers exclusive and proprietary technologies like the FreshWater® Salt System and Smart Monitoring IQ. Together they let you know exactly what you need to maintain clear and natural water.

A LEADER IN ENERGY EFFICIENCY

Limelight Collection® spas offer the very best in energy saving designs and are equipped with an Energy Smart® System. A FiberCor® Foam Insulation and a Titanium No Fault® Heater work together to ensure that your spa will be hot when you are ready, all the while keeping energy costs low.

SEE THINGS IN A WHOLE NEW LIGHT

You can count on lasting quality and unparalleled customer care from a global, top-selling brand. From their dramatic shell design, stainless steel jet details and beautiful LED lights, a Limelight® Collection spa will surely turn heads.

ADDITIONAL SPECS

CLEAN WATER FEATURES

Dual Action Filtration System

FreshWater® Salt System Included

FreshWater® Salt Monitoring System Included

SilentFlo 5000® Circulation Pump

Floor Drain

ENERGY EFFICIENCY

FiberCor® High-Density Insulation

Titanium No-Fault®4,000 W / 230 V Heater

Patented Pump Shroud

Custom-Fit Insulated Cover, WeatherPro™4" Tapered Core with Hinge Seal

Polyethelyne Sealed Bottom

Meets California Energy Commission (CEC) and APSP 14 Energy Efficiency Standards for Portable Spas

INTUITIVE CONTROL

IQ 2020® with Color LCD Touchscreen

230 V / 50 amp, 60 Hz, Includes G.F.C.I. Protected Subpanel

Diagnostic and Ready Hot Spring Logo Light

DESIGN

Vidro®Backlit Ribbon Waterfall

Multi-Color LED Points of Light

Multi-Color LED Lighting with Timer

Customizable Outer Cabinet and Shell

Multi-Color LED Lighting with Timer

WARRANTY

No-Leak Shell: 7 Years

Shell Surface: 7 Years

Cabinet: 5 Years

No-Leak Plumbing: 5 Years

No-Fault® Heater: 5 Years

Component Warranty: 5 Years

Interior Light Assembly: 2 Year
